Decimation Lowpass Filters for SIGMA-DELTA Modulators - A Comparative Study

$65.42List Price: $74.50
Save $9.08!
ISBN: 3640862651
ISBN13: 9783640862658
Formats

Conditions

A brand-new, unused copy in perfect condition.

Formats

Conditions

A brand-new, unused copy in perfect condition.

See all 2 editionsfrom $65.42

Book Overview

Master's Thesis from the year 1998 in the subject Electrotechnology, grade: 1,0 (A), University of Rhode Island (--), language: English, abstract: The purpose of this thesis is to compare several filter topologies used for the decimation of sigma-delta modulated digital signals. The goal is to present optimized filter architectures with regard to an efficient VLSI implementation. A fifth-order 1-bit sigma-delta modulator using local feedback techniques will be considered as the front-end A/D converter. The subsequent digital filter reduces the sampling rate by a factor of 32. The decimation filter must guarantee a narrow transition band between 0.5 and 0.55 and stopband attenuation of 100dB. Chapter 1 provides a brief introduction into the principles of digital signal processing. The considerations are focused on FIR filters due to the requirements for acoustic applications. Chapter 2 illustrates the proposed overall structure and the design flow. The objective of chapter 3 is to present the principles of oversampling data converters using sigma-delta techniques. The 5V fifth-order SigmaDelta-modulator with 90dB dynamic range (SNR+THD) will be presented, which has been fabricated in 1.2$um CMOS technology. For the sake of simplicity and robustness, a 1-bit quantizer will be used. Chapter 4 deals with typical hardware realizations of digital filters. Apart from the brute force'' implementation of the multirate filter with identical filters running in parallel, also the LUT-based approach for small filter orders will be presented. Due to the advantages of compact implementation, the bit-serial approach and the bit-serial multiplier are investigated in detail. In chapter 5 the straightforward one-stage multirate FIR filter will be introduced. To satisfy the specifications, a 4096 tap lowpass FIR filter will be designed. The influence of coefficient quantization is investigated and furthermore the block scaling'' method, to represent small values, is presente
Format:
Paperback
Language:
English
ISBN:
3640862651
ISBN13:
9783640862658
Release Date:
March 2011
Publisher:
Grin Verlag
Length:
188 Pages
Weight:
0.56 lbs.
Dimensions:
0.4″ × 5.8″ × 8.3″
