Visualization and Animation of a Missile/Target Encounter

By Jeffery T Bush

Existing missile/target encounter modeling and simulation systems focus on improving probability of kill models. Little research has been done to visualize these encounters. These systems can be made more useful to the engineers by incorporating current computer graphics technology for visualizing and animating the encounter. Our research has been to develop a graphical simulation package for visualizing both endgame and full fly-out encounters. Endgame visualization includes showing the interaction of a missile, its fuze cone proximity sensors, and its target during the final fraction of a second of the missile/target encounter. Additionally, this system displays dynamic effects such as the warhead fragmentation pattern and the specific skewing of the fragment scattering due to missile yaw at the point of detonation. Fly-out visualization, on the other hand, involves full animation of a missile from launch to target. Animating the results of VisSim fly-out simulations provides the engineer a more efficient means of analyzing his data. This research also involves investigating fly-out animation via the World Wide Web.

This work has been selected by scholars as being culturally important, and is part of the knowledge base of civilization as we know it. This work was reproduced from the original artifact, and remains as true to the original work as possible. Therefore, you will see the original copyright references, library stamps (as most of these works have been housed in our most important libraries around the world), and other notations in the work.

This work is in the public domain in the United States of America, and possibly other nations. Within the United States, you may freely copy and distribute this work, as no entity (individual or corporate) has a copyright on the body of the work.

As a reproduction of a historical artifact, this work may contain missing or blurred pages, poor pictures, errant marks, etc. Scholars believe, and we concur, that this work is important enough to be preserved, reproduced, and made generally available to the public. We appreciate your support of the preservation process, and thank you for being an important part of keeping this knowledge alive and relevant.

• Format: Paperback
• Language: English
• ISBN: 1249578647
• ISBN13: 9781249578642
• Release Date: October 2012
• Publisher: Biblioscholar
• Length: 114 Pages
• Weight: 0.38 lbs.
• Dimensions: 0.2" x 6.1" x 9.2"
