Semiconductor device and image processing method: United States Patent 9986196

By: Hamasaki, Hiroyuki

An image processing apparatus includes an image processing unit that calculates two types of image data from one image data and outputs the calculated image data, a data combination unit that combines the two type of data supplied from the image processing unit and outputs the combined data to one terminal, an output buffer that adjusts an output timing of the combined data according to an instruction supplied from bus arbitration means for arbitrating a bus, and a data distribution unit that outputs the combined data output from the output buffer to the bus in a form of the combined data, or distributes the combined data and outputs the distributed data to the bus according to an external combination distribution instruction.

• Format: Paperback
• Language: English
• ISBN: B08RGZBJFM
• ISBN13: 9798585710599
• Release Date: January 1
• Publisher: Independently Published
• Length: 26 Pages
• Weight: 0.19 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
