Real-Time Electromagnetic Transient Simulation of Ac-DC Networks

By Venkata Dinavahi and Ning Lin

This book provides a detailed exposition of field-programmable gate array (FPGA) hardware-based real-time electromagnetic transient (EMT) emulation for all the fundamental equipment used in an AC-DC power system. Specific focus is afforded to: (a) detailed device-level models for their hardware realization in a massively parallel and deeply pipelined manner, and (b) decomposition techniques for emulating large systems. Case studies provided in the book range from small didactic test circuits to realistic-sized large-scale AC-DC grids. In each of chapter, different models, solution algorithms, and hardware emulation are provided. In the first chapter, the FPGA and hardware-in-the-loop (HIL) emulation procedure are introduced, which will be used in following chapters. And the last chapter covers large-scale networks, which are constructed by fundamental components explained in previous chapters.

• Format: Hardcover
• Language: English
• ISBN: 1119695449
• ISBN13: 9781119695448
• Release Date: June 2021
• Publisher: Wiley-IEEE Press
• Length: 608 Pages
• Weight: 2.13 lbs.
• Dimensions: 1.3" x 6.0" x 9.0"
