Working Principal & Technical Details On First Electrolyte Injection Equipment: Lithium-Ion Cell Battery Manufacturing

By Mr Vivek T

The equipment is recommended to be equipped with integrated electronic scale. If the weighing sensor is used, the repeating accuracy of the weighing sensor is 0.1g, the resolution is 0.01g, the stability is reliable, and the weighing sensor is required to be protected by stainless steel shell; Weighing communication needs to use anti-interference module, the line needs to be fixed to reduce the joint and prevent hanging.
The weighing mechanism is equipped with one-click spot detection function and a set of calibration weights, including but not limited to １*1000g，１*５000g; It is equipped with a non-metallic pad for placing the weight
Test probe life >=1 million times; Probe head has gold-plated copper design, no scratches, pits and other appearance problems, probe life cycle control, control times can be set, after the life expires alarm will be triggered to stop the machine
The information such as Hi-pot test voltage, Hi-pot test resistance, Hi-pot test time, detection results and so on are corresponding to the scanning bar code one by one, and the corresponding information is stored in industrial PC and uploaded to MES system; (test time 200-4ooms, judgement standard Vd1 The cell, the cup body and the digital display gauge correspond one by one, realizing injection in part of the pallet, and the elastic design of the liquid injection needle. It is necessary to consider the internal and external friction and isolation of the spring to prevent powder dropping and liquid injection crystallization corrosion.

• Format: Paperback
• Language: English
• ISBN: B0F7HYPC6F
• ISBN13: 9798282495546
• Release Date: April 2025
• Publisher: Independently Published
• Length: 100 Pages
• Weight: 0.32 lbs.
• Dimensions: 0.2" x 6.0" x 9.0"
