Virtual image display apparatus: United States Patent 9979936

By: Takagi, Masayuki

In a projection system, a nonaxisymmetric aspheric surface is used as a surface that is located in a position where in a pencil of light of video image light that exits from each of two points in different corner regions in an image plane that is a light exiting plane of an image display apparatus, light components that should reach a viewer's eyes do not intersect one another, whereby the size of an optical system can be further reduced and the size of an overall apparatus can therefore be reduced with a variety of types of optical precision, such as the resolution and angle of view, maintained.
