User's Manual for the Model Interface and Plugboard Cabinets in the 14- By 22-Foot Subsonic Tunnel

By: Nasa, National Aeronautics and Space Adm

The primary method of connection between the wind tunnel model instrumentation and the data acquisition system in the 14- by 22-Foot Subsonic Tunnel is through the Model Interface (MIF) and Plugboard cabinets. The MIF and Plugboard cabinets allow versatility in the connection of the instrumentation to the different data systems in the facility. The User's Manual describes the components inside the MIF cabinet, the input and output of the MIF, and the MIF patchboard, and the Plugboard cabinets. There are examples of standard connections for most of the instrumentation used in the facility. Askew, Robert B. and Quinto, P. Frank Langley Research Center...
