Use of SX Series Devices and IEEE 1149.1 Jtag Circuitry

By National Aeronautics and Space Administration

This report summarizes the use of SX series devices and their JTAG 1149.1 circuitry. 'JTAG' circuitry was originally designed to standardize testing of boards via a simple control port interface electrically without having to use devices such as a bed of nails tester. JTAG is also used for other functions such as executing built-in-test sequences, identifying devices, or, through custom instructions, other functions designed in by the chip designer. The JTAG circuitry is designed for test only; it has no functional use in the integrated circuit during normal operations. The JTAG circuitry and the mode of the device is controlled by a circuit block known as the 'TAP controller, ' which is a sixteen-state state machine along with various registers. The controller is normally in an operational state known as TEST-LOGIC-RESET. In this state, the device is held in a fully functional, operational mode. However, a Single Event Upset (SEU) may remove the TAP controller from this state, causing a loss of control of the integrated circuit, unless certain precautions are taken, such as grounding the optional JTAG TRST signal. Katz, Richard B. and Wang, J. J. Goddard Space Flight Center ...

• Format: Paperback
• Language: English
• ISBN: 1792959915
• ISBN13: 9781792959912
• Release Date: January 1
• Publisher: Independently Published
• Length: 30 Pages
• Weight: 0.21 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
