Updated Users' Guide for Tawfive with Multigrid

By: Nasa, National Aeronautics and Space Adm

A program for the Transonic Analysis of a Wing and Fuselage with Interacted Viscous Effects (TAWFIVE) was improved by the incorporation of multigrid and a method to specify lift coefficient rather than angle-of-attack. A finite volume full potential multigrid method is used to model the outer inviscid flow field. First order viscous effects are modeled by a 3-D integral boundary layer method. Both turbulent and laminar boundary layers are treated. Wake thickness effects are modeled using a 2-D strip method. A brief discussion of the engineering aspects of the program is given. The input, output, and use of the program are covered in detail. Sample results are given showing the effects of boundary layer corrections and the capability of the lift specification method. Melson, N. Duane and Streett, Craig L. Langley Research Center...

• Format: Paperback
• Language: English
• ISBN: 1730898416
• ISBN13: 9781730898419
• Release Date: January 1
• Publisher: Independently Published
• Length: 68 Pages
• Weight: 0.40 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
