Turbulence Model Comparisons for a High-Speed Aircraft

By National Aeronautics and Space Administration

Four turbulence models are described and evaluated for transonic flows over the High-Speed Research/industry baseline configuration known as Reference H by using the thin-layer, upwind, Navier-Stokes solver known as CFL3D. The turbulence models studied are the equilibrium model of Baldwin-Lomax (B-L) with the Degani-Schiff (D-S) modifications, the one-equation Baldwin-Barth (B-B) model, the one-equation Spalart-Allmaras (S-A) model, and Menter's two-equation Shear Stress Transport (SST) model. The flow conditions, which correspond to tests performed in the National Transonic Facility (NTF) at Langley Research Center, are a Mach number of 0.90 and a Reynolds number of 30 x 10 (exp. 6) based on mean aerodynamic chord for angles of attack of 1 deg., 5 deg., and 10 deg. The effects of grid topology and the representation of the actual wind tunnel model geometry are also investigated. Computed forces and surface pressures compare reasonably well with the experimental data for all four turbulence models.Rivers, Melissa B. and Wahls, Richard A.Langley Research CenterCOMPUTATIONAL FLUID DYNAMICS; COMPUTATIONAL GRIDS; NAVIER-STOKES EQUATION; TURBULENCE MODELS; TRANSONIC WIND TUNNELS; SUPERSONIC AIRCRAFT; APPLICATIONS PROGRAMS (COMPUTERS); WIND TUNNEL TESTS; BALDWIN-LOMAX TURBULENCE MODEL; ANGLE OF ATTACK; GRID GENERATION (MATHEMATICS); MATHEMATICAL MODELS; TOPOLOGY; SHEAR STRESS

• Format: Paperback
• Language: English
• ISBN: 1723905046
• ISBN13: 9781723905049
• Release Date: January 1
• Publisher: Independently Published
• Length: 60 Pages
• Weight: 0.36 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
