Tool for Generation of Mac/GMC Representative Unit Cell for CMC/Pmc Analysis

By National Aeronautics and Space Administration

This document describes a recently developed analysis tool that enhances the resident capabilities of the Micromechanics Analysis Code with the Generalized Method of Cells (MAC/GMC) 4.0. This tool is especially useful in analyzing ceramic matrix composites (CMCs), where higher fidelity with improved accuracy of local response is needed. The tool, however, can be used for analyzing polymer matrix composites (PMCs) as well. MAC/GMC 4.0 is a composite material and laminate analysis software developed at NASA Glenn Research Center. The software package has been built around the concept of the generalized method of cells (GMC). The computer code is developed with a user friendly framework, along with a library of local inelastic, damage, and failure models. Further, application of simulated thermomechanical loading, generation of output results, and selection of architectures to represent the composite material have been automated to increase the user friendliness, as well as to make it more robust in terms of input preparation and code execution. Finally, classical lamination theory has been implemented within the software, wherein GMC is used to model the composite material response of each ply. Thus, the full range of GMC composite material capabilities is available for analysis of arbitrary laminate configurations as well. The primary focus of the current effort is to provide a graphical user interface (GUI) capability that generates a number of different user-defined repeating unit cells (RUCs). In addition, the code has provisions for generation of a MAC/GMC-compatible input text file that can be merged with any MAC/GMC input file tailored to analyze composite materials. Although the primary intention was to address the three different constituents and phases that are usually present in CMCs-namely, fibers, matrix, and interphase-it can be easily modified to address two-phase polymer matrix composite (PMC) materials where an interphase is absent. Currently, the too

• Format: Paperback
• Language: English
• ISBN: 1793983577
• ISBN13: 9781793983572
• Release Date: January 1
• Publisher: Independently Published
• Length: 26 Pages
• Weight: 0.19 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
