Three-Dimensional Trajectory Analyses of Two Drop Sizing Instruments: PMS Oap and PMS Fssp

By: Nasa, National Aeronautics and Space Adm

Flow induced distortions of water drop fluxes and speeds seen by the instruments were predicted by use of three dimensional flow and trajectory calculation methods. Sensitivities were determined for the instruments, in isolation and mounted under the wing of an airplane, to: water drop diameter (2 to 1000 microns), angle of attack and free stream air speed. For the optical array probe in isolation and on the airplane at 0 deg angle of attack, flux distortions of practical consequence are not found. At 4 deg airplane angle of attack, partial flow stagnation under the uptilted wing causes significant decreases in both flux and speed for cloud size droplets. For the forward scattering spectrometer probe in isolation, only marginally significant sensitivities to free stream air speed are found, and no sensitivity is found to angle of attack. Both speed and flux of cloud size droplets are predicted to be undermeasured by from 12 to 24 percent depending on airplane angle of attack. For the wing-mounted instruments, effects of flow about the instruments themselves are found to be equal in importance to effects of flow about the airplane. Preferred orientation (canting) angles of distorted water drops are found to be functions of drop size, angle of attack and air speed. Norment, Hillyer G. Unspecified Center...

• Format: Paperback
• Language: English
• ISBN: 1730896200
• ISBN13: 9781730896200
• Release Date: January 1
• Publisher: Independently Published
• Length: 68 Pages
• Weight: 0.40 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
