The Use Of Swimmer Bars As Shear Reinforcement In Concrete Flat Plates

By Moayyad Al-Nasra

Swimmer bars are a new type of shear reinforcement. They are short inclined steel bars welded to both top and bottom flexural reinforcement. Punching shear takes the form of a truncated pyramid or a truncated cone. A counteract truncated pyramid or a truncated cone of reinforcement formed by swimmer bars will be employed to generate four inclined planes (in the case of truncated pyramid) crossing the four inclined planes of the cracks and a conical surface (for the case of truncated conical shape of failure). The results obtained from plates provided with these plane-crack interceptors, proved the effectiveness of this new system. The number of truncated pyramid-crack interceptors may be increased for heavy punching shear forces. The provision of these swimmer bars has the potential to eliminate the need of drop panels in flat slabs and raft foundation in the vicinity of columns, leading to savings and ease of construction. The results of this study are particularly useful to the design and construction engineering professionals.

• Format: Paperback
• Language: English
• ISBN: 3639511654
• ISBN13: 9783639511659
• Release Date: February 2013
• Publisher: Scholars' Press
• Length: 136 Pages
• Weight: 0.46 lbs.
• Dimensions: 0.3" x 6.0" x 9.0"
