The Core Test Wrapper Handbook: Rationale and Application of IEEE Std. 1500(tm)

By Teresa McLaurin, Tom Waayers, Francisco da Silva

Book Overview

In the early to mid-1990's while working at what was then Motorola Se- conductor, business changes forced my multi-hundred dollar microprocessor to become a tens-of-dollars embedded core. I ran into first hand the problem of trying to deliver what used to be a whole chip with something on the order of over 400 interconnect signals to a design team that was going to stuff it into a package with less than 220 signal pins and surround it with other logic. I also ran into the problem of delivering microprocessor specification verifi- tion - a microprocessor is not just about the functions and instructions included with the instruction set, but also the MIPs rating at some given f- quency. I faced two dilemmas: one, I could not deliver functional vectors without significant development of off-core logic to deal with the reduced chip I/O map (and everybody's I/O map was going to be a little different); and two, the JTAG (1149. 1) boundary scan ring that was around my core when it was a chip was going to be woefully inadequate since it did not support - speed signal application and capture and independent use separate from my core. I considered the problem at length and came up with my own solution that was predominantly a separate non-JTAG scan test wrapper that supported at-speed application of launch-capture cycles using the system clock. But my problems weren't over at that point either.

• Format: Paperback
• Language: English
• ISBN: 148998769X
• ISBN13: 9781489987693
• Release Date: October 2014
• Publisher: Springer
• Length: 276 Pages
• Weight: 0.96 lbs.
• Dimensions: 0.7" x 6.1" x 9.2"
