Testing and Analysis of Composite Skin/Stringer Debonding Under Multi-Axial Loading

By National Aeronautics and Space Administration

Damage mechanisms in composite bonded skin/stringer constructions under uniaxial and biaxial (in-plane/out- of-plane) loading conditions were examined. Specimens consisted of a tapered composite flange bonded onto a composite skin. Tests were performed under monotonic loading conditions in tension, three-point bending, and combined tension/bending . For combined tension/bending testing, a unique servohydraulic load frame was used that was capable of applying both in-plane tension and out-of-plane bending loads simultaneously. Specimen edges were examined on the microscope to document the damage occurrence and to identify typical damage patterns. The observations showed that, for all three load cases, failure initiated in the flange, near the flange tip, causing the flange to almost fully debond from the skin. A two-dimensional plane-strain finite element model was developed to analyze the different test cases using a geometrically nonlinear solution. For all three loading conditions, principal stresses exceeded the transverse strength of the material in the flange area. Additionally, delaminations of various lengths were simulated in two locations where delaminations were observed. The analyses showed that unstable delamination propagation is likely to occur in one location at the loads corresponding to matrix ply crack initiation for all three load cases.Krueger, Ronald and Cvitkovich, Michael K. and OBrien, T. Kevin and Minguet, Pierre J.Langley Research CenterCOMPOSITE MATERIALS; STRINGERS; AXIAL LOADS; SKIN (STRUCTURAL MEMBER); DAMAGE; TESTS; DEBONDING (MATERIALS); FINITE ELEMENT METHOD; FRACTURE MECHANICS; FLANGES; PLANE STRAIN; TWO DIMENSIONAL MODELS; COMPOSITE STRUCTURES; STRESS ANALYSIS

• Format: Paperback
• Language: English
• ISBN: 1723894451
• ISBN13: 9781723894459
• Release Date: January 1
• Publisher: Independently Published
• Length: 60 Pages
• Weight: 0.36 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
