Techniques for Transition and Surface Temperature Measurements on Projectiles at Hypersonic Velocities- A Status Report

By: Administration (Nasa), National Aeronaut

A research effort to advance techniques for determining transition location and measuring surface temperatures on graphite-tipped projectiles in hypersonic flight in a ballistic range is described. Projectiles were launched at muzzle velocities of approx. 4.7 km/sec into air at pressures of 190-570 Torr. Most launches had maximum pitch and yaw angles of 2.5-5 degrees at pressures of 380 Torr and above and 3-6 degrees at pressures of 190-380 Torr. Arcjet-ablated and machined, bead-blasted projectiles were launched; special cleaning techniques had to be developed for the latter class of projectiles. Improved methods of using helium to remove the radiating gas cap around the projectiles at the locations where ICCD (intensified charge coupled device) camera images were taken are described. Two ICCD cameras with a wavelength sensitivity range of 480-870 nm have been used in this program for several years to obtain images. In the last year, a third camera, with a wavelength sensitivity range of 1.5-5 microns in the infrared (IR)], has been added. ICCD and IR camera images of hemisphere nose and 70 degree sphere-cone nose projectiles at velocities of 4.0-4.7 km/sec are presented. The ICCD images clearly show a region of steep temperature rise indicative of transition from laminar to turbulent flow. Preliminary temperature data for the graphite projectile noses are presented. Wilder, M. C. and Bogdanoff, D. W. Ames Research Center; NASA Headquarters NASA/TM-2005-212831, A-0412610 NAS2-99092 HYPERSONICS; SURFACE TEMPERATURE; PROJECTILES; BALLISTIC RANGES; PITCH (INCLINATION); TURBULENT FLOW; TRANSITION TEMPERATURE; CHARGE COUPLED DEVICES; INFRARED RADIATION; GRAPHITE; HELIUM

• Format: Paperback
• Language: English
• ISBN: B08F6Y3QWM
• ISBN13: 9798672679808
• Release Date: January 1
• Publisher: Independently Published
• Length: 34 Pages
• Weight: 0.23 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
