Tds and Bmt for Cases Adf (Adf Rams), Acceptance Test

By National Aeronautics and Space Administration

The Controls, Astrophysics, and Structures Experiment (CASES) is a proposed experiment to collect x ray images of the galactic center and solar disk with unprecedented resolution. This requires precision pointing and suppression of vibrations in the long, flexible structure that comprises the 32-m x ray telescope optical bench. Two separate electro-optical sensors systems are provided for the ground test facility (GTF). The Boom Motion Tracker (BMT) measures eigenvector data for post-mission use in system identification. The Tip Displacement Sensor (TDS) measures boom tip position and is used as feedback for the closed-loop control system that stabilizes the boom. The deployment and testing of the BMT and TDS systems is summarized. Davis, Hugh W. Unspecified Center BOOMS (EQUIPMENT); CONTROL SYSTEMS DESIGN; ELECTRO-OPTICS; FLEXIBLE BODIES; LARGE SPACE STRUCTURES; MEASURING INSTRUMENTS; POINTING CONTROL SYSTEMS; SPACECRAFT CONTROL; X RAY TELESCOPES; ATTITUDE INDICATORS; DISPLACEMENT; FEEDBACK CONTROL; GROUND TESTS; STRUCTURAL VIBRATION; TEST FACILITIES; X RAY ASTRONOMY...

• Format: Paperback
• Language: English
• ISBN: 1731038054
• ISBN13: 9781731038050
• Release Date: January 1
• Publisher: Independently Published
• Length: 110 Pages
• Weight: 0.60 lbs.
• Dimensions: 0.2" x 8.5" x 11.0"
