Systems and methods for MEMS gyroscope shock robustness: United States Patent 9995583

By: Rocchi, Alessandro

Various embodiments of the invention allow for increased shock robustness in gyroscopes. In certain embodiments, immunity against undesired forces that corrupt signal output is provided by a chessboard-pattern architecture of proof masses that provides a second layer of differential signals not present in existing designs. Masses are aligned parallel to each other in a two-by-two configuration with two orthogonal symmetry axes. The masses are driven to oscillate in such a way that each mass moves anti-parallel to an adjacent proof mass. In some embodiments of the invention, a mechanical joint system interconnects proof masses to suppress displacements due to mechanical disturbances, while permitting displacements due to Coriolis forces to prevented erroneous sensor signals.

• Format: Paperback
• Language: English
• ISBN: B08RGV6W94
• ISBN13: 9798585971747
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
