Suggested Procedures for Installing Strain Gauges on Langley Research Center Wind Tunnel Balances, Custom Force Measuring Transducers, Metallic and Co

By National Aeronautics and Space Administration

The character of force and strain measurement testing at LaRC is such that the types of strain gauge installations, the materials upon which the strain gauges are applied, and the test environments encountered, require many varied approaches. In 1997, a NASA Technical Memorandum (NASA TM 110327) was generated to provide the strain gauge application specialist with a listing of recommended procedures for strain gauging various transducers and test articles at LaRC. The technical memorandum offered here is an effort to keep the strain gauge user informed of new technological enhancements in strain-gauging methodology while preserving the strain-gauging guidelines set forth in the 1997 TM. This document provides detailed recommendations for strain gauging LaRC-designed balances and custom transducers, composite materials, cryogenic and high-temperature test articles, and selected non-typical or unique materials or test conditions. Additionally, one section offers details for installing Bragg-Grating type fiber-optic strain sensors for non-typical test scenarios. Moore, Thomas C., Sr. Langley Research Center NASA/TM-2004-213017, L-19020 23-761-20-5H

• Format: Paperback
• Language: English
• ISBN: B08GFS1VYK
• ISBN13: 9798676361198
• Release Date: January 1
• Publisher: Independently Published
• Length: 72 Pages
• Weight: 0.42 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
