Standard Methods for Bolt-Bearing Testing of Textile Composites

By National Aeronautics and Space Administration

The response of three 2-D braided materials to bolt bearing loading was evaluated using data generated by Boeing Defense and Space Group in Philadelphia, PA. Three test methods, stabilized single shear, unstabilized single shear, and double shear, were compared. In general, these textile composites were found to be sensitive to bolt bearing test methods. The stabilized single shear method yielded higher strengths than the unstabilized single shear method in all cases. The double shear test method always produced the highest strengths but these results may be somewhat misleading. It is therefore recommended that standard material comparisons be made using the stabilized single shear test method. The effects of two geometric parameters, W/D and e/D, were also studied. An evaluation of the effect of the specimen width (W) to hole diameter (D) ratio concluded that bolt bearing responses were consistent with open hole tension results. A W/D ratio of 6 or greater should be maintained. The proximity of the hole to the specimen edge significantly affected strength. In all cases, strength was improved by increasing the ratio of the distance from the hole center to the specimen edge (e) to the hole diameter (D) above 2. An e/D ratio of 3 or greater is recommended. Portanova, M. A. and Masters, J. E. Langley Research Center NAS1-19000; RTOP 505-63-50-04...

• Format: Paperback
• Language: English
• ISBN: 1728933463
• ISBN13: 9781728933467
• Release Date: January 1
• Publisher: Independently Published
• Length: 34 Pages
• Weight: 0.23 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
