Space Shuttle Main Engine Structural Analysis and Data Reduction/Evaluation. Volume 2: High Pressure Oxidizer Turbo-Pump Turbine End Bearing Analysis

By National Aeronautics and Space Administration

The high-pressure oxidizer turbopump (HPOTP) consists of two centrifugal pumps, on a common shaft, that are directly driven by a hot-gas turbine. Pump shaft axial thrust is balanced in that the double-entry main inducer/impeller is inherently balanced and the thrusts of the preburner pump and turbine are nearly equal but opposite. Residual shaft thrust is controlled by a self-compensating, non-rubbing, balance piston. Shaft hang-up must be avoided if the balance piston is to perform properly. One potential cause of shaft hang-up is contact between the Phase 2 bearing support and axial spring cartridge of the HPOTP main pump housing. The status of the bearing support/axial spring cartridge interface is investigated under current loading conditions. An ANSYS version 4.3, three-dimensional, finite element model was generated on Lockheed's VAX 11/785 computer. A nonlinear thermal analysis was then executed on the Marshall Space Flight Center Engineering Analysis Data System (EADS). These thermal results were then applied along with the interference fit and bolt preloads to the model as load conditions for a static analysis to determine the gap status of the bearing support/axial spring cartridge interface. For possible further analysis of the local regions of HPOTP main pump housing assembly, detailed ANSYS submodels were generated using I-DEAS Geomod and Supertab (Appendix A). Sisk, Gregory A. Unspecified Center...

• Format: Paperback
• Language: English
• ISBN: 1730942741
• ISBN13: 9781730942747
• Release Date: January 1
• Publisher: Independently Published
• Length: 86 Pages
• Weight: 0.49 lbs.
• Dimensions: 0.2" x 8.5" x 11.0"
