Sheet Metal Drafting

By Elsworth M Longfield

This vintage book contains an instructional treatise on sheet metal drafting. It aims to presents the underlying principles of sheet metal pattern drafting, with each chapter discussing a different principle in depth. With detailed illustrations and a wealth of useful, practicable information, this volume will be of considerable utility to anyone with an interest in the subject. Contents include: "Sheet Metal Drafting", "Orthographic Projection", "Drawing Instruments", "Lines", "Dimensions", "Lettering", "Titles", "Filing Circles", "The Sheet Metal Cleat", "Related Mathematics on Sheet Metal Cleat", "The Galvanized Match Box", "Related Mathematics on Galvanized Match Box", "The Candy Pan", et cetera. Many vintage books such as this are increasingly scarce and expensive. We are republishing this volume now in an affordable, modern edition complete with a specially commissioned new introduction on metal work. First published in 1921.

• Format: Paperback
• Language: English
• ISBN: 147332890X
• ISBN13: 9781473328907
• Release Date: May 2016
• Publisher: Owen Press
• Length: 250 Pages
• Weight: 0.71 lbs.
• Dimensions: 0.6" x 5.5" x 8.5"
