Semiconductor device and method of manufacturing same: United States Patent 9972555

By: Kuroda, Soshi

To provide a semiconductor device having improved reliability. The semiconductor device has a wiring board, bonding land, semiconductor chip mounted on the wiring board via an adhesive layer and having a pad electrode, bonding wire connecting the pad electrode with the bonding land, and sealing body. The sealing body is, in a circuit formation region, in contact with an organic protection film and, in a scribe region and a region between the pad electrode and the scribe region, in contact with a surface protection film while not in contact with the organic protection film. A first side surface is closer to the circuit formation region side than a second one. The adhesive layer covers entirety of the semiconductor chip back surface and the second side surface of the semiconductor chip. The first side surface is in contact with the sealing body without being covered with the adhesive layer.

• Format: Paperback
• Language: English
• ISBN: B08RGZBJNV
• ISBN13: 9798585718113
• Release Date: January 1
• Publisher: Independently Published
• Length: 26 Pages
• Weight: 0.19 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
