Residual Strength Analyses of Riveted Lap-Splice Joints

By: Nasa, National Aeronautics and Space Adm

The objective of this paper was to analyze the crack-linkup behavior in riveted-stiffened lap-splice joint panels with small multiple-site damage (MSD) cracks at several adjacent rivet holes. Analyses are based on the STAGS (STructural Analysis of General Shells) code with the critical crack-tip-opening angle (CTOA) fracture criterion. To account for high constraint around a crack front, the "plane strain core" option in STAGS was used. The importance of modeling rivet flexibility with fastener elements that accurately model load transfer across the joint is discussed. Fastener holes are not modeled but rivet connectivity is accounted for by attaching rivets to the sheet on one side of the cracks that simulated both the rivet diameter and MSD cracks. Residual strength analyses made on 2024-T3 alloy (1.6-mm thick) riveted-lap-splice joints with a lead crack and various size MSD cracks were compared with test data from Boeing Airplane Company. Analyses were conducted for both restrained and unrestrained buckling conditions. Comparison of results from these analyses and results from lap-splice-joint test panels, which were partially restrained against buckling indicate that the test results were bounded by the failure loads predicted by the analyses with restrained and unrestrained conditions.Seshadri, B. R. and Newman, J. C., Jr.Langley Research CenterLAP JOINTS; RIVETED JOINTS; STRUCTURAL ANALYSIS; RIVETS; CRACKS; CRACK PROPAGATION; FRACTURING; HOLES (MECHANICS); RESIDUAL STRENGTH; COMPUTER PROGRAMS; CRACK TIPS; BUCKLING; ALUMINUM ALLOYS; DAMAGE; FAILURE; FASTENERS; LOADS (FORCES)
