Relay abnormality detection device and power conditioner: United States Patent 9970988

By: Lung, Chienru

A relay abnormality detection device to detect an abnormality of a grid interconnection relay upon switching to grid independent operation and includes an abnormality detector to execute commercial power system voltage for determining whether or not there is a commercial power system voltage, if there is commercial power system voltage through the commercial power system voltage determination, first current determination of abnormality determination as to the specific relay according to whether or not there is an input current to the power conditioner in a state where a contact of the specific relay is controlled to open, and if there is no commercial power system voltage through commercial power system voltage determination, second current determination of abnormality determination as to the specific relay according to whether or not there is an output current from the power conditioner in the state where the contact of the specific relay is controlled to open.

• Format: Paperback
• Language: English
• ISBN: B08RGTG3HQ
• ISBN13: 9798585588921
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
