Positioning features for electrical contacts of a replaceable unit of an electrophotographic image forming device: United States Patent 9983541

By: Amann, Mark William

A replaceable imaging basket for an electrophotographic image forming device according to one embodiment includes a frame having a positioning slot that is open at a top of the frame for receiving a replaceable unit. An electrical connector is positioned on an inner side of the frame adjacent to the positioning slot. The electrical connector includes an electrical contact on a front of the electrical connector that faces the positioning slot. The electrical connector includes a pair of outer guides and a pair of inner guides on opposite sides of the electrical contact. The inner guides are spaced inward from the outer guides. A top portion of a front surface of each of the outer guides tapers rearward away from the positioning slot as they extend upward. A top portion of a rear surface of each of the inner guides tapers forward toward the positioning slot as they extend upward.

• Format: Paperback
• Language: English
• ISBN: B08RHZLG7S
• ISBN13: 9798585422324
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
