Phased Array Noise Source Localization Measurements of an F404 Nozzle Plume at Both Full and Model Scale

By: Administration (Nasa), National Aeronaut

A 48-microphone planar phased array system was used to acquire jet noise source localization data on both a full-scale F404-GE-F400 engine and on a 1/4th scale model of a F400 series nozzle. The full-scale engine test data show the location of the dominant noise sources in the jet plume as a function of frequency for the engine in both baseline (no chevron) and chevron configurations. Data are presented for the engine operating both with and without afterburners. Based on lessons learned during this test, a set of recommendations are provided regarding how the phased array measurement system could be modified in order to obtain more useful acoustic source localization data on high-performance military engines in the future. The data obtained on the 1/4th scale F400 series nozzle provide useful insights regarding the full-scale engine jet noise source mechanisms, and document some of the differences associated with testing at model-scale versus fullscale. Podboy, Gary G. and Bridges, James E. and Henderson, Brenda S. Glenn Research Center NASA/TM-2010-216366, GT2010-22601, E-17302 WBS 561581.02.08.03.18.02 JET AIRCRAFT NOISE; NOISE GENERATORS; SOUND GENERATORS; ENGINE NOISE; ENGINE TESTS; FULL SCALE TESTS; PHASED ARRAYS; PLUMES; PLANAR STRUCTURES; SCALE MODELS

• Format: Paperback
• Language: English
• ISBN: B08F6X4PJN
• ISBN13: 9798672752334
• Release Date: January 1
• Publisher: Independently Published
• Length: 36 Pages
• Weight: 0.24 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
