Oxide Scales Formed on NiTi and NiPtTi Shape Memory Alloys

By: Administration (Nasa), National Aeronaut

Ni-49Ti and Ni-30Pt-50Ti (at.%) shape memory alloys were oxidized isothermally in air over the temperature range of 500 to 900 C. The microstructure, composition, and phase content of the scales were studied by SEM, EDS, XRD, and metallography. Extensive plan view SEM/EDS identified various features of intact or spalled scale surfaces. The outer surface of the scale was a relatively pure TiO2 rutile structure, typified by a distinct highly striated and faceted crystal morphology. Crystal size increased significantly with temperature. Spalled regions exhibited some porosity and less distinct features. More detailed information was obtained by correlation of SEM/EDS studies of 700 C/100 hr cross-sections with XRD analyses of serial or taper-polishing of plan surfaces. Overall, multiple layers exhibited graded mixtures of NiO, TiO2, NiTiO3, Ni(Ti) or Pt(Ni, Ti) metal dispersoids, Ni3Ti or Pt3Ti depletion zones, and substrate, in that order. The NiTi alloy contained a 3 at.% Fe impurity that appeared in embedded localized Fe-Ti-rich oxides, while the NiPtTi alloy contained a 2 v/o dispersion of TiC that appeared in lower layers. The oxidation kinetics of both alloys (in a previous report) indicated parabolic growth and an activation energy (250 kJ/mole) near those reported in other Ti and NiTi studies. This is generally consistent with TiO2 existing as the primary scale constituent, as described here. Smialek, James L. and Garg, Anita and Rogers, Richard B. and Noebe, Ronald D. Glenn Research Center NASA/TM-2011-217096, E-17748 NICKEL ALLOYS; METALLOGRAPHY; SHAPE MEMORY ALLOYS; REACTION KINETICS; POROSITY; OXIDATION; ISOTHERMAL PROCESSES; TITANIUM ALLOYS; TITANIUM OXIDES; CRYSTAL MORPHOLOGY; BINARY ALLOYS; POLISHING; TAPERING; SUBSTRATES; IMPURITIES; EMBEDDING; MICROSTRUCTURE

• Format: Paperback
• Language: English
• ISBN: B08F6YD2C6
• ISBN13: 9798672344652
• Release Date: January 1
• Publisher: Independently Published
• Length: 38 Pages
• Weight: 0.25 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
