Optical Fiber Data Transfer System

By: Nasa, National Aeronautics and Space Adm

This Phase 2 effort applies the results of Phase 1 to design and fabricate an optical slip ring system for a helicopter rotor blade/wind tunnel application. In this application, there are two assemblies: one on the rotating portion of the mechanical system, one on the stationary portion. The assembly on the rotating portion digitizes and encodes 128 transducer signals from various parts of the blade, and optically transfers data across the noncontacting coupling. Two complete identical independent channels are provided. On the stationary side, the signals are decoded and one channel is transmitted in digital form to a computer for recording and analysis. The second channel reconstructs the analog transducer signals for real time observation. In the opposite direction, eight signal channels enable control signals to be passed from the stationary to the rotating part of the system. Power to the rotor mounted electronics is supplied via power slip rings. The advantages of the optical over the traditional electro-mechanical slip ring method of data transfer across a rotating joint are long life, low-maintenance, immunity to crosstalk, and wider bandwidth. Successful completion of this effort demonstrated that this method is practical and reliable, and can be implemented under difficult conditions of available space, power, environment, and stringent performance and equipment life requirements. Mcmillan, S. H. Unspecified Center DATA TRANSFER (COMPUTERS); FIBER OPTICS; RING STRUCTURES; ROTOR BLADES (TURBOMACHINERY); SIGNAL PROCESSING; WIND TUNNEL APPARATUS; ELECTRO-OPTICS; HELICOPTER DESIGN; REAL TIME OPERATION...

• Format: Paperback
• Language: English
• ISBN: 1731304471
• ISBN13: 9781731304476
• Release Date: January 1
• Publisher: Independently Published
• Length: 126 Pages
• Weight: 0.68 lbs.
• Dimensions: 0.3" x 8.5" x 11.0"
