On the Coupling of Cdisc Design Method with Fpx Rotor Code

By: Nasa, National Aeronautics and Space Adm

A rotor section aerodynamics design package is developed by coupling Constrained Direct Iterative Surface Curvature (CDISC) design method with the FPX rotor code. The coupling between the CDISC design and the FPX flow analysis is fully automated. The CDISC design method employs a predictor-corrector procedure iteratively to determine a surface geometry which produces a target pressure distribution, where the target pressure distributions is either pre-defined or automatically generated through flow and geometry constraints. The FPX code is an eXtended Full-Potential rotor Computational Fluid Dynamics (CFD) code, which solves the three-dimensional unsteady full-potential equation in a strong conservative form using an implicit approximate factorization finite-difference scheme with entropy and viscosity corrections. Application of the CDISC design method coupled with the FPX rotor code is made for rotor blades in hovering motions. Several design examples are presented to demonstrate the capability of the new package in rotor section design.Hu, Hong and Jones, Henry E. (Technical Monitor)Langley Research CenterCOMPUTATIONAL FLUID DYNAMICS; PREDICTOR-CORRECTOR METHODS; FLOW DISTRIBUTION; ROTOR AERODYNAMICS; PRESSURE DISTRIBUTION; COMPUTER PROGRAMS

• Format: Paperback
• Language: English
• ISBN: 1723745677
• ISBN13: 9781723745676
• Release Date: January 1
• Publisher: Independently Published
• Length: 42 Pages
• Weight: 0.27 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
