On-Orbit Structural Dynamic Performance of a 15-Meter Microwave Radiometer Antenna

By: Nasa, National Aeronautics and Space Adm

The on-orbit structural dynamic performance of a microwave radiometer antenna for Earth science applications is addressed. The radiometer is one of the Earth-observing instruments aboard a proposed geostationary platform as part of the Mission to the Planet Earth. A sequential approach is presented for assessing the ability of an antenna structure to retain its geometric shape subject to a representative onboard disturbance. This approach includes establishing the structural requirements of the antenna, developing the structural and disturbance models, performing modal and forced response analyses, and evaluating the resulting distortions in terms of the antenna's ability to meet stringent structural performance requirements. Two antenna configurations are discussed: free-flying and platform-mounted. These configurations are analyzed for a representative disturbance function which simulates rotation of the subreflector in order to perform a raster-type scan of the Earth disk. Results show that the scanning maneuver modeled would not induce antenna structural errors outside the specified limits. Wahls, Deborah M. and Farmer, Jeffery T. and Sleight, David W. Langley Research Center RTOP 506-49-21-02...

• Format: Paperback
• Language: English
• ISBN: 1729221343
• ISBN13: 9781729221341
• Release Date: January 1
• Publisher: Independently Published
• Length: 46 Pages
• Weight: 0.29 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
