Numerical Investigations in Three-Dimensional Internal Flows

By: Nasa, National Aeronautics and Space Adm

The flow in the transonic test facility was investigated using the three dimensional computational fluid dynamics techniques. The application of the full Navier-Stokes three dimensional code to the flow qualities in the contraction section of transonic wind tunnel is discussed. Initially, two dimensional solutions indicated the possibility for large secondary flow to exist as a result of the asymmetries involved in the contraction section as it is constructed. The results of a full three dimensional solution indicate that only minor pressure variations actually occur in the contraction section within any given cross flow plane. Further analysis of the three dimensional solution indicated that these slight lateral pressure gradients lead to negligible secondary flows, except within a small region in the corners within the boundary layer. On the basis of present solution, it would not be expected that any flow asymmetries and/or secondary flow present within contraction section are associated with the methods by which the contraction is implemented in its present configuration. Rose, William C. Unspecified Center NCC2-507...

• Format: Paperback
• Language: English
• ISBN: 1729110134
• ISBN13: 9781729110133
• Release Date: January 1
• Publisher: Independently Published
• Length: 30 Pages
• Weight: 0.21 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
