Network Topology: The Physical and Logical Structure of a Network connection Between Model and nodes

By Engr. Wilson Kurt

Network Topology is a structural network layout that is either physical or logical and arranged by a pattern of connected computers, devices, nodes, and other links of a network. It has different structures of a network topology that shows how a network is created and connected a link (in different methods) to a device. Such network topology structures are bus, ring, mesh, fully connected (or complete), star, and hierarchical (tree). Computers MUST connect to a network of any topology because of information sharing and communication. Without a network, users are unable to share files, send emails, print files, creating and sharing database, etc. An example of this is a Local Area Network (LAN). Any node in the LAN has one or more links to other devices within the network, mapping these links can result in a geometric shape.Network Topology refers to the layout of a network and how different nodes in a network are connected to each other and how they communicate. Topologies are either physical (the physical layout of devices on a network) or logical (the way that the signals act on the network media, or the way that the data passes through the network from one device to the next). This Webopedia Study Guide describes five of the most common network topologies. A network topology is the arrangement of nodes -- usually switches, routers, or software switch/router features -- and connections in a network, often represented as a graph. The topology of the network, and the relative locations of the source and destination of traffic flows on the network, determine the optimum path for each flow and the extent to which redundant options for routing exist in the event of a failure. There are two ways of defining network geometry: the physical topology and the logical (or signal) topology.

• Format: Paperback
• Language: English
• ISBN: 1672463599
• ISBN13: 9781672463591
• Release Date: December 2019
• Publisher: Independently Published
• Length: 60 Pages
• Weight: 0.22 lbs.
• Dimensions: 0.1" x 6.0" x 9.0"
