Multi-band device having multiple miniaturized single-band power amplifiers: United States Patent 9979349

By: Lehtola, Philip John

Multi-band device having multiple miniaturized single-band power amplifiers. In some embodiments, a power amplifier die can include a semiconductor substrate, and a plurality of power amplifiers (PAs) implemented on the semiconductor substrate. Each PA can be configured to drive approximately a characteristic load impedance of a downstream component along an individual frequency band signal path, such that each PA is sized smaller than a wide band PA configured to drive more than one of the frequency bands associated with the plurality of PAs. The downstream component can include an output filter.

• Format: Paperback
• Language: English
• ISBN: B08RGXBFHZ
• ISBN13: 9798585215650
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
