Modular illumination and sensor chamber: United States Patent 9983139

By: Cooper, Donald Channing

Embodiments described are generally directed to a test sample apparatus. The test sample apparatus generally comprises a holder base arranged that accommodates a tablet or cell phone. The apparatus has a hood that is placed over a portion of the tablets illuminating touchscreen such that the illuminating touchscreen provides light that can be collected by the hood. There is a chamber integrated with the hood adapted to accommodate a chemically activated test strip. The chemically activated test strip is illuminated when the hood collects light from the illuminating touchscreen. A lens in the hood interposed between the camera and the test strip enables the camera to focus on a portion of the chemically activated test strip when the hood is placed over the portion of the illuminating touchscreen.
