Miniature Drag-Force Anemometer

By: Nasa, National Aeronautics and Space Adm

A miniature drag-force anemometer is described which is capable of measuring dynamic velocity head and flow direction. The anemometer consists of a silicon cantilever beam 2.5 mm long, 1.5 mm wide, and 0.25 mm thick with an integrated diffused strain-gage bridge, located at the base of the beam, as the force measuring element. The dynamics of the beam are like those of a second-order system with a natural frequency of about 42 kHz and a damping coefficient of 0.007. The anemometer can be used in both forward and reversed flow. Measured flow characteristics up to Mach 0.6 are presented along with application examples including turbulence measurements. Krause, L. N. and Fralick, G. C. Glenn Research Center NASA-TM-X-3507, E-9087 RTOP 505-04

• Format: Paperback
• Language: English
• ISBN: 1719976651
• ISBN13: 9781719976657
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
