Mechanical Design Engineering Enabler Project Wheel and Wheel Drives

By National Aeronautics and Space Administration

Our group was assigned the responsibility of designing the wheel and wheel drive system for a proof-of-concept model of the lunar-based ENABLER. ENABLER is a multi-purpose, six wheeled vehicle designed to lift and transport heavy objects associated with the construction of a lunar base. The resulting design was based on the performance criteria of the ENABLER. The drive system was designed to enable the vehicle to achieve a speed of 7 mph on a level surface, climb a 30 percent grade, and surpass a one meter high object and one meter wide crevice. The wheel assemblies were designed to support the entire weight of the vehicle on two wheels. The wheels were designed to serve as the main component of the vehicle's suspension and will provide suitable traction for lunar-type surfaces. The expected performance of the drive system for the ENABLER was influenced by many mechanical factors. The expected top speed on a level sandy surface is 4 mph instead of the desired 7 mph. This is due to a lack of necessary power at the wheels. The lack of power resulted from dimension considerations that allowed only an eight horsepower engine and also from mechanical inefficiencies of the hydraulic system. However, the vehicle will be able to climb a 30 percent grade, surpass a one meter high object and one meter wide crevice. The wheel assemblies will be able to support the entire weight of the vehicle on two wheels. The wheels will also provide adequate suspension for the vehicle and sufficient traction for lunar-type surfaces. Nutt, Richard E. and Couch, Britt K. and Holley, John L., Jr. and Garris, Eric S. and Staut, Paul V. Unspecified Center NASW-4435...

• Format: Paperback
• Language: English
• ISBN: 1729338755
• ISBN13: 9781729338759
• Release Date: January 1
• Publisher: Independently Published
• Length: 42 Pages
• Weight: 0.27 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
