M.E.366-J Embodiment Design Project: Portable Foot Restraint

By: Nasa, National Aeronautics and Space Adm

During space shuttle operations, astronauts require support to carry out tasks in the weightless environment. In the past, portable foot restraints (PFR) with orientations adjustable in pitch, roll, and yaw provided this support for payload bay operations. These foot restraints, however, were designed for specific tasks with a load limit of 111.2 Newtons. Since the original design, new applications for foot restraints have been identified. New designs for the foot restraints have been created to boost the operational work load to 444.8 Newtons and decrease setup times. What remains to be designed is an interface between the restraint system and the extravehicular mobility unit (EMU) boots. NASA provided a proposed locking device involving a spring-loaded mechanism. This locking mechanism must withstand loads of 1334.4 Newtons in any direction and weigh less than 222.4 Newtons. This paper develops an embodiment design for the interface between the PFR and the EMU boots. This involves design of the locking mechanism and a removable cleat that allows the boot to interface with this mechanism. The design team used the Paul Beitz engineering methodology to present the systematic development, structural analysis, and production considerations of the embodiment design. This methodology provides a basis for understanding the justification behind the decisions made in the design. Heaton, Randall and Meyer, Eikar and Schmidt, Davey and Enders, Kevin Unspecified Center NASW-4435...

• Format: Paperback
• Language: English
• ISBN: 1729333613
• ISBN13: 9781729333617
• Release Date: January 1
• Publisher: Independently Published
• Length: 50 Pages
• Weight: 0.31 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
