Magnetic Field Response Measurement Acquisition System

By: Administration (Nasa), National Aeronaut

A measurement acquisition method that alleviates many shortcomings of traditional measurement systems is presented in this paper. The shortcomings are a finite number of measurement channels, weight penalty associated with measurements, electrical arcing, wire degradations due to wear or chemical decay and the logistics needed to add new sensors. The key to this method is the use of sensors designed as passive inductor-capacitor circuits that produce magnetic field responses. The response attributes correspond to states of physical properties for which the sensors measure. A radio frequency antenna produces a time-varying magnetic field used to power the sensor and receive the magnetic field response of the sensor. An interrogation system for discerning changes in the sensor response is presented herein. Multiple sensors can be interrogated using this method. The method eliminates the need for a data acquisition channel dedicated to each sensor. Methods of developing magnetic field response sensors and the influence of key parameters on measurement acquisition are discussed. Woodard, Stanley E. and Taylor, Bryant D. and Shams, Qamar A. and Fox, Robert L. Langley Research Center NASA/TM-2005-213518, L-19074 23-762-65-AT MAGNETIC MEASUREMENT; DATA ACQUISITION; SYSTEMS HEALTH MONITORING; MAGNETIC FIELDS; MULTISENSOR FUSION; RADIO FREQUENCIES

• Format: Paperback
• Language: English
• ISBN: B08F6CG957
• ISBN13: 9798672475059
• Release Date: January 1
• Publisher: Independently Published
• Length: 40 Pages
• Weight: 0.26 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
