Macro Fiber Piezocomposite Actuator Poling Study

By: Nasa, National Aeronautics and Space Adm

The performance and advantages of Piezocomposite Actuators are to provide a low cost, in-situ actuator/sensor that is flexible, low profile and high strain per volt performance in the same plane of poled voltage. This paper extends reported data for the performance of these Macrofiber Composite (MFC) Actuators to include 4 progressively narrower Intedigitized electrode configurations with several line widths and spacing ratios. Data is reported for max free strain, average strain per applied volt, poling (alignment of the electric dipoles of the PZT ceramic) voltage vs. strain and capacitance, time to poling voltage 95% saturation. The output strain per volt progressively increases as electrode spacing decreases, with saturation occurring at lower poling voltages. The narrowest spacing ratio becomes prone to voltage breakdown or short circuits limiting the spacing width with current fabrication methods. The capacitance generally increases with increasing poling voltage level but has high sensitivity to factors such as temperature, moisture and time from poling which limit its usefulness as a simple indicator. The total time of applied poling voltage to saturate or fully line up the dipoles in the piezoceramic was generally on the order of 5-20 seconds. Less sensitivity to poling due to the applied rate of voltage increase over a 25 to 500 volt/second rate range was observed.Werlink, Rudy J. and Bryant, Robert G. and Manos, DennisLangley Research CenterACTUATORS; PIEZOELECTRIC CERAMICS; FIBER COMPOSITES; FABRICATION; ELECTRIC POTENTIAL; LOW COST; STRAIN GAGES; CAPACITANCE; ELECTRIC DIPOLES; SHORT CIRCUITS; LEAD ZIRCONATE TITANATES

• Format: Paperback
• Language: English
• ISBN: 1723737372
• ISBN13: 9781723737374
• Release Date: January 1
• Publisher: Independently Published
• Length: 28 Pages
• Weight: 0.20 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
