Longitudinal-Control Design Approach for High-Angle-Of-Attack Aircraft

By: Nasa, National Aeronautics and Space Adm

This paper describes a control synthesis methodology that emphasizes a variable-gain output feedback technique that is applied to the longitudinal channel of a high-angle-of-attack aircraft. The aircraft is a modified F/A-18 aircraft with thrust-vectored controls. The flight regime covers a range up to a Mach number of 0.7; an altitude range from 15,000 to 35,000 ft; and an angle-of-attack (alpha) range up to 70 deg, which is deep into the poststall region. A brief overview is given of the variable-gain mathematical formulation as well as a description of the discrete control structure used for the feedback controller. This paper also presents an approximate design procedure with relationships for the optimal weights for the selected feedback control structure. These weights are selected to meet control design guidelines for high-alpha flight controls. Those guidelines that apply to the longitudinal-control design are also summarized. A unique approach is presented for the feed-forward command generator to obtain smooth transitions between load factor and alpha commands. Finally, representative linear analysis results and nonlinear batch simulation results are provided. Ostroff, Aaron J. and Proffitt, Melissa S. Langley Research Center RTOP 505-64-30-01...

• Format: Paperback
• Language: English
• ISBN: 1729008283
• ISBN13: 9781729008287
• Release Date: January 1
• Publisher: Independently Published
• Length: 36 Pages
• Weight: 0.24 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
