Kinematics of Hooke Universal Joint Robot Wrists

By National Aeronautics and Space Administration

The singularity problem associated with wrist mechanisms commonly found on industrial manipulators can be alleviated by redesigning the wrist so that it functions as a three-axis gimbal system. This paper discussess the kinematics of gimbal robot wrists made of one and two Hooke universal joints. Derivations of the resolved rate motion control equations for the single and double Hooke universal joint wrists are presented using the three-axis gimbal system as a theoretical wrist model. Mckinney, William S., Jr. Langley Research Center RTOP 549-02-41-01...

• Format: Paperback
• Language: English
• ISBN: 1729001556
• ISBN13: 9781729001554
• Release Date: January 1
• Publisher: Independently Published
• Length: 34 Pages
• Weight: 0.23 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
