Investigation Into Spectroscopic Techniques for Thermal Barrier Coating Spall Detection

By: Nasa, National Aeronautics and Space Adm

Spectroscopic methods are proposed for detection of thermal barrier coating (TBC) spallation from engine hot zone components. These methods include absorption and emission of airborne marker species originally embedded in the TBC bond coat. In this study, candidate marker materials for this application were evaluated. Thermochemical analysis of candidate marker materials combined with additional constraints such as toxicity and uniqueness to engine environment, provided a short list of four potential species: platinum, copper oxide, zinc oxide. and indium. The melting point of indium was considered to be too low for serious consideration. The other three candidate marker materials, platinum, copper oxide, and zinc oxide were placed in a high temperature furnace and emission and absorption properties were measured over a temperature range from 800-1400 C and a spectral range from 250 to 18000 nm. Platinum did not provide the desired response, likely due to the low vapor Pressure of the metallic species and the low absorption of the oxide species. It was also found, however. that platinum caused a broadening of the carbon dioxide absorption at 4300 nm. The nature of this effect is not known. Absorption and emission caused by sodium and potassium impurities in the platinum were found in the platinum tests. Zinc oxide did not provide the desired response, again, most likely due to the low vapor pressure of the metallic species and the low absorption of the oxide species. Copper oxide generated two strongly temperature dependent absorption peaks at 324.8 and 327.4 nm. The melting point of copper oxide was determined to be too low for serious consideration as marker material.deGroot, Wim and Opila, BethGlenn Research CenterSPECTROSCOPY; THERMAL CONTROL COATINGS; SPALLATION; THERMAL BARRIERS (PLASMA CONTROL); ABSORPTION; EMISSION; ENGINE PARTS; THERMOCHEMISTRY; MELTING POINTS; CARBON DIOXIDE; MARKERS

• Format: Paperback
• Language: English
• ISBN: 1723732877
• ISBN13: 9781723732874
• Release Date: January 1
• Publisher: Independently Published
• Length: 30 Pages
• Weight: 0.21 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
