Installed F/A-18 Inlet Flow Calculations at 30 Degrees Angle-Of-Attack: A Comparative Study

By: Nasa, National Aeronautics and Space Adm

NASA Lewis is currently engaged in a research effort as a team member of the High Alpha Technology Program (HATP) within NASA. This program utilizes a specially equipped F/A-18, the High Alpha Research Vehicle (HARV), in an ambitious effort to improve the maneuverability of high-performance military aircraft at low subsonic speed, high angle of attack conditions. The overall objective of the Lewis effort is to develop inlet technology that will ensure efficient airflow delivery to the engine during these maneuvers. One part of the Lewis approach utilizes computational fluid dynamics codes to predict the installed performance of inlets for these highly maneuverable aircraft. Full Navier-Stokes (FNS) calculations on the installed F/A-18 inlet at 30 degrees angle of attack, 0 degrees yaw, and a freestream Mach number of 0.2 have been obtained in this study using an algebraic turbulence model with two grids (original and revised). Results obtained with the original grid were used to determine where further grid refinements and additional geometry were needed. In order to account properly for the external effects, the forebody, leading edge extension (LEX), ramp, and wing were included with inlet geometry. In the original grid, the diverter, LEX slot, and leading edge flap were not included due to insufficient geometry definition, but were included in a revised grid. In addition, a thin-layer Navier-Stokes (TLNS) code is used with the revised grid and the numerical results are compared to those obtained with the FNS code. The TLNS code was used to evaluate the effects on the solution using a code with more recent CFD developments such as upwinding with TVD schemes versus central differencing with artificial dissipation. The calculations are compared to a limited amount of available experimental data. The predicted forebody/fuselage surface static pressures compared well with data of all solutions. The predicted trajectory of the vortex generated under the LEX was differe...

• Format: Paperback
• Language: English
• ISBN: 172936070X
• ISBN13: 9781729360705
• Release Date: January 1
• Publisher: Independently Published
• Length: 56 Pages
• Weight: 0.34 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
