Independent Peer Review of Communications, Navigation, and Networking re-Configurable Testbed (CoNNeCT) Project Antenna Pointing Subsystem (APS) Integ

By: Administration (Nasa), National Aeronaut

Glenn Research Center Chief Engineer's Office requested an independent review of the structural analysis and modeling of the Communications, Navigation, and Networking re-Configurable Testbed (CoNNeCT) Project Antenna Pointing Subsystem (APS) Integrated Gimbal Assembly (IGA) to be conducted by the NASA Engineering and Safety Center (NESC). At this time, the IGA had completed its critical design review (CDR). The assessment was to be a peer review of the NEi-NASTRAN1 model of the APS Antenna, and not a peer review of the design and the analysis that had been completed by the GRC team for CDR. Thus, only a limited amount of information was provided on the structural analysis. However, the NESC team had difficulty separating analysis concerns from modeling issues. The team studied the NASTRAN model, but did not fully investigate how the model was used by the CoNNeCT Project and how the Project was interpreting the results. The team's findings, observations, and NESC recommendations are contained in this report. Raju, Ivatury S. and Larsen, Curtis E. and Pellicciotti, Joseph W. Goddard Space Flight Center; Johnson Space Center; Langley Research Center NASA/TM-2010-216870, NESC-RP-10-00635, L-19949, NF1676L-11793 NAVIGATION; STRUCTURAL ANALYSIS; GIMBALS; ANTENNA DESIGN; NASTRAN; MATHEMATICAL MODELS; COMMUNICATION NETWORKS; FREE VIBRATION; KINEMATICS; RANDOM VIBRATION; STRESS ANALYSIS; DATA PROCESSING

• Format: Paperback
• Language: English
• ISBN: B08FNK8VZF
• ISBN13: 9798673360026
• Release Date: January 1
• Publisher: Independently Published
• Length: 64 Pages
• Weight: 0.38 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
