High Temperature Strain Gage Technology for Hypersonic Aircraft Development Applications

By: Nasa, National Aeronautics and Space Adm

An experimental evaluation of Pd 13 percent Cr and of BCL-3 alloy wire strain gages was conducted on IN100 and Cu 0.15 percent Zr alloy substrates. Testing included apparent strain, drift, gage factor, and creep. Maximum test temperature was 1144 K (1600 F). The PdCr gages incorporated Pt temperature compensation elements. The PdCr gages were found to have good resistance stability below 866 K (1100 F). The BCL 3 gages were found to have good resistance stability above 800 K (981 F), but high drift around 700 K (800 F). Anderson, W. L. and Grant, H. P. Unspecified Center...

• Format: Paperback
• Language: English
• ISBN: 1729356079
• ISBN13: 9781729356074
• Release Date: January 1
• Publisher: Independently Published
• Length: 56 Pages
• Weight: 0.34 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
