High Temperature Strain Gage Technology for Gas Turbine Engines

By: Nasa, National Aeronautics and Space Adm

This report summarizes the results of a six month study that addressed specific issues to transfer the Pd-13Cr static strain sensor to a gas turbine engine environment. The application issues that were addressed include: (1) evaluation of a miniature, variable potentiometer for use as the ballast resistor, in conjunction with a conventional strain gage signal conditioning unit; (2) evaluation of a metal sheathed, platinum conductor leadwire assembly for use with the three-wire sensor; and (3) subjecting the sensor to dynamic strain cyclic testing to determine fatigue characteristics. Results indicate a useful static strain gage system at all temperature levels up to 1350 F. The fatigue characteristics also appear to be very promising, indicating a potential use in dynamic strain measurement applications. The procedure, set-up, and data for all tests are presented in this report. This report also discusses the specific strain gage installation technique for the Pd-13Cr gage because of its potential impact on the quality of the output data. Fichtel, Edward J. and Mcdaniel, Amos D. Unspecified Center NAS3-25952...

• Format: Paperback
• Language: English
• ISBN: 172902131X
• ISBN13: 9781729021316
• Release Date: January 1
• Publisher: Independently Published
• Length: 26 Pages
• Weight: 0.19 lbs.
• Dimensions: 0.1" x 8.5" x 11.0"
