High-Efficiency 20 Ghz Traveling Wave Tube Development for Space Communications

By: Nasa, National Aeronautics and Space Adm

A 75 watt CW high efficiency helix TWT operating at 20 GHz was developed for satellite communication systems. The purpose was to extend the performance capabilities of helix TWTs by using recent technology developments. The TWT described is a unique design because high overall efficiency is obtained with a low perveance beam. In the past, low perveance designs resulted in low beam efficiencies. However, due to recent breakthoughs in diamond rod technology and in collector electrode materials, high efficiencies can now be achieved with low perveance beams. The advantage of a low perveance beam is a reduction in space charge within the beam which translates to more efficient collector operation. In addition, this design incorporates textured graphite electrodes which further enhance collector operation by suppressing backstreaming secondaries. The diamond supported helix circuit features low RF losses, high interaction impedance, good thermal handling capability and has been designed to compensate for the low perveance beam. One more discussed tube feature is the use of a velocity taper in the output helix that achieves low signal distortion while maintaining high efficiency. Aldana, S. L. and Tamashiro, R. N. Unspecified Center...

• Format: Paperback
• Language: English
• ISBN: 1730953697
• ISBN13: 9781730953699
• Release Date: January 1
• Publisher: Independently Published
• Length: 96 Pages
• Weight: 0.54 lbs.
• Dimensions: 0.2" x 8.5" x 11.0"
