Geometric Dimensioning and Tolerancing Handbook: A Practical Guide to ASME Y14.5 Symbols, Datums, and Feature Control Frames for Engineers

By MindForge Press

The complete, modern guide to Geometric Dimensioning and Tolerancing.

Master the language of precision engineering. GD&T is the symbolic language that defines how much a manufactured part may vary and still work - and this handbook teaches all of it, from first principles to advanced application, in one rigorous, richly illustrated volume built around ASME Y14.5-2018 with ISO GPS comparisons throughout.

Whether you are an engineering student, a practicing mechanical or manufacturing engineer, a machinist, a quality inspector, or a designer, this book takes you from why a round tolerance zone accepts more good parts than a square one all the way to composite position, profile, runout, tolerance stack-up, and functional gauge design - with every equation derived, every worked example solved step by step, and every practice problem answered.

Inside, you will learn to: read and write feature control frames, datums, and every geometric symbol; apply material condition modifiers (MMC, LMC, RFS) and compute bonus tolerance and virtual condition; build datum reference frames and use datum targets on castings, forgings, and non-rigid parts; master position, profile, orientation, form, and runout through fully worked examples; perform tolerance stack-up analysis (worst-case and statistical) and design functional gauges; and connect GD&T to limits & fits (ISO 286), surface texture, CAD / model-based definition, and inspection.

What sets this handbook apart: 27 chapters, 170+ technical figures, roughly 100 fully worked examples, a comprehensive problem set with solutions, complete case studies that tolerance real parts end to end, and quick-reference appendices. A book to learn from and a reference to keep on the bench.

Stop guessing what a drawing means. Speak the language of precision - clearly, correctly, and with confidence.

• Format: Paperback
• Language: English
• ISBN: B0HBZJ3W7P
• ISBN13: 9798189628085
• Release Date: July 2026
• Publisher: Independently Published
• Length: 368 Pages
• Weight: 1.88 lbs.
• Dimensions: 0.8" x 8.5" x 11.0"
