Generation and Computerized Simulation of Meshing and Contact of Modified Involute Helical Gears

By: Nasa, National Aeronautics and Space Adm

The design and generation of modified involute helical gears that have a localized and stable bearing contact, and reduced noise and vibration characteristics are described. The localization of the bearing contact is achieved by the mismatch of the two generating surfaces that are used for generation of the pinion and the gear. The reduction of noise and vibration will be achieved by application of a parabolic function of transmission errors that is able to absorb the almost linear function of transmission errors caused by gear misalignment. The meshing and contact of misaligned gear drives can be analyzed by application of computer programs that have been developed. The computations confirmed the effectiveness of the proposed modification of the gear geometry. A numerical example that illustrates the developed theory is provided. Litvin, Faydor L. and Chen, Ningxin and Lu, Jian Unspecified Center...

• Format: Paperback
• Language: English
• ISBN: 1730914632
• ISBN13: 9781730914638
• Release Date: January 1
• Publisher: Independently Published
• Length: 78 Pages
• Weight: 0.45 lbs.
• Dimensions: 0.2" x 8.5" x 11.0"
